Square Bar Cutting Machine

Name: Square Bar Cutting Machine
Brand: ICON Industries
Price: 150000 INR
Availability: InStock

Price 150000 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Square Bar Cutting Machine Specification

Product Type
Square Bar Cutting Machine

General Use
Industrial

Material
MS

Weight (kg)
500 Kilograms (kg)

Automatic
Yes

Control System
PLC Control

Drive Type
Electric

Voltage
415 Volt (v)

Dimension (L*W*H)
900 x 500 x 1100 Millimeter (mm)

Color
Red

Square Bar Cutting Machine Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
10 Pieces Per Day

Delivery Time
1 Days

About Square Bar Cutting Machine

Square Bar Cutting Machine we present is engineered for making shearing, punching, pipe notching, and various other metal fabrication functions faster and easier. Idea for angle patti, channel, flat bar, I-section, and square & round bar, the machine has usage in various industries such as Metal Fabrication work, Construction Metal Fabrications, Bridge Manufacturing, Tower manufacturing, Telecommunication Industries, etc. Square Bar Cutting Machine is operated with the help of control foot paddle, and other separate functions are safely performed without interference at the same time.

Product Details :

Max. Cutting Stroke Speed	48 times/min
Max Punching Force	360 kN
Size	900 x 500 x 1100 mm
Automatic Grade	Semi-Automatic
Phase	Three Phase
Motor Capacity (hp)	3 HP
Power Source	415 V
Motor Power (kW)	2.2 kW
Weight (Kg)	500kg
Model Name/Number	QA32
Brand	ICON
Material	Mild Steel
Usage/Application	Industrial

ICONs Multipurpose Ironworker Machine can be used for punching, shearing, notching, and other metal fabrication functions. It is a unique machine that has various applications and serves a lot of industries such as Metal Fabrication work, Tower manufacturing, Construction Metal Fabrications, Telecommunication Industries, Bridge Manufacturing, etc.

These are well-engineered ironworkers built for high power, quality, and reliability. These ironworkers have a control foot paddle, and separate operations can be safely performed simultaneously without interference.

APPLICATION :

Cutting and Shearing of:

Angle Patti
Channel
I-Section
Flat Bar
Round & square bar

It is also used for:

Punching
Notching
Pipe notching

Characteristics:

Adopt high quality copper wire motor, enhanced machine rack, compact structure, solid and reliable.
Good lubricating property.
Less functional loss compared with same type cutting machine, load power can be largely reduced.

Category: IRONWORKER MACHINE

Tags: angle cutting machine, fabrication machine, flat bar shearing machine, ironworker machine, multipurpose ironworker machine, rod shearing machine, shearing machine, square bar shearing machine

Precision and Automation for Industrial Cutting

This Square Bar Cutting Machine combines precision engineering with automated control, making it ideal for high-volume industrial needs. The PLC system enhances accuracy and minimizes manual intervention, resulting in faster processing and lower labor costs. Its sturdy MS construction ensures longevity even in challenging working conditions.

Efficient Operation with Modern Control Systems

The machines electric drive and programmable PLC control system streamline the cutting process. Users can achieve consistent results with minimal effort, while its compact size allows seamless integration in industrial settings. With a focus on safety and efficiency, this equipment is perfectly tailored for manufacturers and suppliers in India.

FAQs of Square Bar Cutting Machine:

Q: How does the Square Bar Cutting Machine operate?

A: This machine functions automatically through an electric drive system and a PLC-based control unit. Operators simply configure cutting settings and the machine precisely cuts square bars with minimal supervision.

Q: What materials can this cutting machine process?

A: The Square Bar Cutting Machine is constructed from mild steel (MS) and designed to efficiently cut square metal bars, typically used in industrial applications.

Q: When should I use this machine in my manufacturing process?

A: It is ideal for use during the initial stages of production when raw square metal bars need accurate cutting to specified lengths and shapes.

Q: Where is this machine manufactured and supplied?

A: The Square Bar Cutting Machine is manufactured and supplied in India, catering to various industrial sectors and businesses in the region.

Q: What benefits does the PLC control system offer?

A: The PLC control system enhances precision, reduces errors, and provides automated operation, ensuring uniform cuts and increasing overall productivity.

Q: How do I integrate this machine into my workshop?

A: Thanks to its compact dimensions (900 x 500 x 1100 mm) and electric operation, integration simply requires a suitable installation space and a 415 Volt power source.

Q: What is the process for using the machine safely and efficiently?

A: To operate safely, staff should follow manufacturer guidelines, calibrate the PLC system for specific cuts, and maintain the equipment regularly to ensure optimal performance.
